BladeHD Outdoor Splitter Cabinet (FDH–576)
LYNN Outdoor Cabinet, Up to 576 SC/APC Output, 100-ft pigtail, 1 1U BladeHD SC/APC Input 12F 1M pigtail
Designed for FDH deployment with 4U BladeHD enclosures for up to 576 SC/APC outputs with 1U BladeHD for SC/APC inputs, painted stainless steel.
Includes: 12-fiber 1 m pigtail for inputs, 1U BladeHD enclosures for SC/APC outputs, preinstalled 100 ft outdoor pigtails.
- Installs on Pole or Pad
- Up to 576 SC Ports
- Available with Ruggedized Outdoor Splitters
- Painted Stainless Steel
- Vented Top
Technical Specifications
| Brand | LYNN |
|---|---|
| Rack Spaces | 11 RU |
| Product Line | BladeHD |
| Product Color | Gray |
| Product Material | Painted Stainless Steel |
| Product Lifecycle | Active |
| Operating Temperature Range | -5°C to 60°C (23°F to 140°F) |
| Mounting Options | Pad Mount, Pole Mount |
| Capacity | 2x 4RU, 360 SC/APC Outputs, 2x 4RU, 384 SC/APC Outputs, 2x 4RU, 432 SC/APC Outputs, 2x 4RU, 504 SC/APC Outputs, 2x 4RU, 528 SC/APC Outputs, 2x 4RU, 576 SC/APC Outputs, 4RU, 144 SC/APC Outputs, 4RU, 288 SC/APC Outputs |
| Product Dimensions | 37.40 in x 29.50 in x 15 in |
