1G Ethernet Media Converter with 1 SFP Slot and 1 PoE+ RJ45 Port

Name: 1G Ethernet Media Converter with 1 SFP Slot and 1 PoE+ RJ45 Port
Brand: ENET
SKU: TL-MC-1S1RPP
Availability: InStock

SKU: TL-MC-1S1RPP Categories: 1G Media Converters, Media Converters, Networking and Media Converters Brand: ENET

ENET 1G Ethernet Media Converter with 1 SFP Slot and 1 RJ45 30W PoE+ Port

TechLogix media converters adapt fiber signals to a variety of different formats and/or cable types.

The TL-MC-1S1RPP features one SFP port (SFP module sold separately) and one RJ45 twisted pair PoE+ port, effectively adapting PoE and PoE+ twisted pair-based devices to fiber for longer transmission distances. The TL-MC-1S1RPP supports multimode fiber when paired with a multimode SFP module and single mode when paired with a single mode SFP module.

Two TL-MC-1S1RPP media converters are required for most applications — one for each end of the cable run.

Technical Specifications

Brand	ENET
RJ45 ports	1
Power Input	5V DC
Non-PoE ports	1
Product Color	Black
Connector Type	RJ45 Female
Power Connector	5.5 mm OD, 2.6 mm ID Barrel
PoE Max Distance	100 m (328 ft)
Product Material	Painted Steel
Product Lifecycle	Active
Relative Humidity	10% to 80% RH, Non-condensing
Fiber Connectivity	SFP
Supported Data Rate	Up to 1 Gbps
Maximum Power Consumption	30 W
Operating Temperature Range	0° C to 50° C (32° F to 122° F)
Compliance	CE, FCC Class A, NDAA, UKCA
Mounting Options	Rack Mount, Surface
PoE Power Rating	POE: 350mA, 12.95W, POE+: 600mA, 25.5W
Ethernet Category Standard	Cat 5e, Cat 6, Cat 6A
HTS Code	8517.62.9000
Product Weight	200 g (0.44 lb)
Product Dimensions	26.25 mm x 70.75 mm x 94 mm (1.03 in x 2.79 in x 3.70 in)
